DC blæser - 40x40x20mm 12Vdc / 0,56W, glideleje, 2 ledn.
Varenr:
H16422
EAN:
5412810159079
Tekniske detaljer:
- Producent (varemærke): SUNON
- Type ventilator: DC, aksial
- Forsyningsspænding: 12Vdc
- Størrrelse: 40x40x20mm
- Effekt: 0,56W
- Strømforbrug: 0,046A
- Luftflow: 15,12m3/t
- Støjniveau: 26,5dBA
- Lejetype: Kugleleje
- Rotationshastighed: 6300 (± 15%) rpm
- Vægt: 33g
- Strømforbrugstolerance: ±15%
- Min. isolationsmodstand: 10Mohm
- Propelmateriale: Termoplast
- Kabinetmateriale: Termoplast
- Isoleringsklasse: A
- Ledninger: 2
- Operationel temperatur: -10...70°C
- Ledningslængde: 305mm
- Statisk tryk: 5,59mm H2O
- Ventilatormotor: børsteløs DC-motor
- Brandbarhed: UL94V-0
- Yderligere funktioner: Autorestart
- Driftsspænding: 4,5...13,8V
- Ledningsstørrelse: 26AWG
Specifications:
- Manufacturer: SUNON
- Type of fan: DC, axial
- Supply voltage: 12V DC
- Fan dimensions: 40x40x20mm
- Power consumption: 0,56W
- Current rating: 0.046A
- Airflow: 15,12m3/h
- Noise level: 26,5dBA
- Kind of Bearing: ball bearing
- Rotational rate/speed: 6300 (±15%)rpm
- Weight: 33g
- Current and power consumption tolerance: ±15%
- Min. insulation resistance: 10Mohm
- Impeller material: thermoplastic
- Enclosure material: thermoplastic
- Insulation class: A
- Leads: 2 leads
- Operating temperature: -10...70°C
- Cable length: 305mm
- Static pressure: 5,59mm H2O
- Fan motor: brushless DC motor
- Flammability rating: UL94V-0
- Additional functions: Autorestart
- Operating voltage: 4,5...13,8V
- Wire size: 26AWG
