230V printtransformator - 5,5VA 2 x 24V / 2x0,114A
Varenr:
H37804
EAN:
5410329260491
Egenskaber:
- Spænding: 2 x 24V
- Strøm: 2 x 0.104A
- Isolation resistance: >5Mohm / 500Vdc
- Electric strength: >5kV min.
- Designed for an ambient temperature of maks. 40°C
- Thermal class E, materials to maks. 120°
- Short-circuit protection up to 3VA
- Possibility of thermal fuse protection
- Maks. temperature for class E: 95°C
- Primary tension: 230V ± 10%, 50/60Hz
- Secondary voltage tolerance: +7% - 3% at 230V and maks. load
- Perfect solderability for wave bath
- CE labelled
- Creepage distances and clearances according to IEC742
- Picture:
- 1*: bobbin with two chambers
- 2*: input winding
- 3*: encapsulation in epoxy resin
- 4*: output winding
- 5*: connection pins
- 6*: polyamide cover
- 7*: magnetic core
- 8*: safety transformer
- 9*: inherently short-circuit proof
- 10*: primary voltage
- 11*: nominal power / temperature
- 12*: manufacturer's reference
- 13*: ordercode
- 14*: meets :
- 15*: nominal secondary voltages
