Heavy duty relæ - 24VDC / 12A, 2 x skifte (DPDT)
Varenr:
H60514
EAN:
5705412605144
Tekniske detaljer:
- Producent (varemærke): TE Connectivity
- Type relæ: Elektromagnetisk
- Kontaktkonfiguration: DPDT
- Nominel spolespænding: 24Vdc
- AC kontaktstrøm (ved resistiv belastning): 12A 250Vac
- DC kontaktstrøm (ved resistiv belastning): 12A 30Vdc
- Maks. kontaktstrøm: 12A
- Maks. Koblet spænding: 300Vdc, maks. 400Vac
- Relævariant: Industriel
- Montering: Printhul
- Relæserie: PT
- Operationel temperatur: -40...70°C
- Husstørrelse: 28x22,5x30mm
- Spolemodstand: 777 Ohm
- Kontaktmateriale: AgNi
- Spolens strømforbrug: 0,75W
- Ledninger: Til PCB
- Ekstra funktion: Testknap med spærrefunktion
- Udgangskonfiguration: (se billeder)
Specifications:
- Manufacturer: TE Connectivity
- Type of relay: Electromagnetic
- Contacts configuration: DPDT
- Rated coil voltage: 24Vdc
- AC contacts rating @R: 12A 250V AC
- DC contacts rating @R: 12A 30Vdc
- Contact current max.: 12A
- Switched voltage: Max. 300Vdc, max. 400V AC
- Relay variant: Industrial
- Mounting: PCB
- Relay series: PT
- Operating temperature: -40...70°C
- Body dimensions: 28x22.5x30mm
- Coil resistance: 777 Ohm
- Contact material: AgNi
- Coil power consumption: 0.75W
- Leads: For PCB
- Optional feature: Test button with blocking function
- Related items: PT78720
- Output configuration: (see images)
