Miniature relæ - 5VDC 10A, 1 x slutte (SPST-NO) 4-ben 2,54mm
Varenr:
H61734
EAN:
5705412617345
Tekniske detaljer:
- Producent (varemærke): TE Connectivity
- Type relæ: Elektromagnetisk
- Kontakter konfiguration: SPST-NR
- Nominel spolespænding: 5Vdc
- Maks. kontaktstrøm: 10A
- AC kontaktstrøm (ved resistiv belastning): 10A / 250Vac
- DC kontaktstrøm (ved resistiv belastning): 10A / 30Vdc
- Maks. Koblet spænding: 30Vdc, maks. 277Vac
- Relævariant: Miniature
- Montering: Printhul
- Spolemodstand: 55,6 Ohm
- Spolespænding min.: 3,5Vdc
- Driftstid: 10ms
- Husstørrelse: 18,2x14,7x10,2mm
- Udgivelsestid: 4ms
- Operationel temperatur: -30...70°C
- Vægt: 9g
- Relæserie: OJ
- Kontaktmateriale: AgCdO
- Terminalafstand: 2,54mm
- Højde: 14,7mm
Specifications:
- Manufacturer: TE Connectivity
- Type of relay: Electromagnetic
- Contacts configuration: SPST-NO
- Rated coil voltage: 5V DC
- Contact current max.: 10A
- AC contacts rating @R: 10A / 250V AC
- DC contacts rating @R: 10A / 30V DC
- Switched voltage: Max. 30V DC, max. 277V AC
- Relay variant: Miniature
- Mounting: PCB
- Coil resistance: 55.6 Ohm
- Coil voltage min.: 3.5V DC
- Operate time: 10ms
- Body dimensions: 18.2x14.7x10.2mm
- Release time: 4ms
- Operating temperature: -30...70°C
- Weight: 9g
- Relay series: OJ
- Contact material: AgCdO
- Terminal pitch: 2.54mm
- Height: 14.7mm
