Automatsikring - 10A / 240V

The T11 series of circuit breakers for equipment is a line of small, single pole push to reset, overload protective devices. The trip mechanism is of the superior «latch type». A high contact force can be maintained until the unit trips. This prevents electrical "noise" due to contact bounce and reduces the risk of contact welding which may occur with spring type mechanism.

The overload sensing is done with the aid of a thermal bimetal which has the advantage of being immune to high inrush currents and line transients. All T11-units are «positively trip-free». The contacts will open and will remain open during an overload. Contacts cannot be held in the closed position and they will not close automatically even if the closing command is maintained.

The T11 is specifically designed to protect equipment, wiring, transformers, power supplies, motors and sub-assemblies, such as printed circuit boards. For non-PCB mounting the T11 is connected to wiring with the popular quick connect terminals. Rated currents can be specified from 0,05 A to 16 A. All models are internationally approved.

The Swiss precision design is simple with few moving parts. This results in an extremely reliable CBE with high resistance against shock and vibration.

Tekniske detaljer:

• Producent: SCHURTER
• Sikringstype: Circuit breaker
• Mærkespænding: 240VAC, 48VDC
• Maks. strøm: 10A
• Kontaktkonfiguration
  : SPST
• Antal poler: 1
• Mekanisk montage: Skrue
• Elektrisk montage: 6,3 x 0,8mm spadestik
• Operationel temperatur: -5...60°C
• Mont. huldiameter: Ø9,6mm
• Dielektrisk styrke: 4kVAC
