230V printtransformator - 5,5VA 2 x 24V / 2x0,114A

Egenskaber:

• Spænding: 2 x 24V
• Strøm: 2 x 0.104A
• Isolation resistance: >5Mohm / 500Vdc
• Electric strength: >5kV min.
• Designed for an ambient temperature of maks. 40°C
• Thermal class E, materials to maks. 120°
• Short-circuit protection up to 3VA
• Possibility of thermal fuse protection
• Maks. temperature for class E: 95°C
• Primary tension: 230V ± 10%, 50/60Hz
• Secondary voltage tolerance: +7% - 3% at 230V and maks. load
• Perfect solderability for wave bath
• CE labelled
• Creepage distances and clearances according to IEC742
• Picture:
  • 1*: bobbin with two chambers
  • 2*: input winding
  • 3*: encapsulation in epoxy resin
  • 4*: output winding
  • 5*: connection pins
  • 6*: polyamide cover
  • 7*: magnetic core
  • 8*: safety transformer
  • 9*: inherently short-circuit proof
  • 10*: primary voltage
  • 11*: nominal power / temperature
  • 12*: manufacturer's reference
  • 13*: ordercode
  • 14*: meets :
  • 15*: nominal secondary voltages
